SPECIFICATION
Infrared oven
Key Features
- Stainless steel housing inside
- Panel heating with 8 infraredquartz-tubes
- Temperature measurement ofmaterial surface by opto-electronicIR-measuring unit
- Touch screen operation
- Multiple-language screen (GER, EN,FR, IT, NL, ES)
- °C / °F shift- timer function
- Heating ramp function (e.g. forpre-preg)
- Graphic display of heating processesprogression
- Memory for user -defined heating processes
- Double wing door with two doubleglass viewing windows
- 1 insertion plate with PTFE foil(exchangeable)
- Access to online user manuals viaQR code scan
- Connection cable with CEE plug,5-pin,
- 16 A Technical data:-
- Interior lighting: 2 x 25 Watt
- Interior dimensions L x W x H: 810 x580 x 540 mm
- Capacity – 250 Ltr
- Number of quartz infrared tubes: 8infrared tubes 390 mm / 460 W(infrared tubes are Replaceable)
- Continuously adjustable temperaturerange: 30 °C – 250 °C (86 °F – 482 °F)
- Power requirements: 380-400 V /50-60 Hz / 3 Ph / 3.7 kW
- Colours optional: RAL 5017 (trafficblue) or RAL 7035 (light grey)
