3Ph Resistive Load Bank

1. 120 KVA Portable Load Bank (Resistive) - 200Y/115V Rated,
2. 3-Phase, 400 Hz,
3. Caster Wheel Mount,
4. NEMA 3R, Yellow and black, W/O Air Duc
5. Portable Load Bank, Resistive
6. Load Element Alloy Resistors
7. 200Y/115V AC, Wye Connection, 3Ph, 4 Wire
8. 120 KVA (120 KW Resistive Load), Continuous Duty
9. 1KW, 2KW, 2KW, 5KW, 10KW, 20KW, 20KW, 30KW, 30KW
10. Operating Condition- Continuous
11. Power Factor- 1.0
12. Load Accuracy- ±5%
13. Sampling Accuracy 0.5 class
14. Voltage, current-, apparent power, power factor, frequency, etc
15. Wire Connection- Copper bar (L1, L2, L3 and N)
16. Cooling Mode - Force-air cooling, air entry from bottom and outlet to the top.
17. Control Mode - PC software remote control with RS485 connection with load bank
18. Resistive Load Elements - Composed of multiple special alloy resistors in parallel. The outer part of the alloy resistor is made of 304 stainless steel sheet as the heat-dissipating material, the outer tube is made of 304 stainless steel tube as anti-rust and anti-corrosion component. The inside is filled with the Magnesium Oxide powder which is thermal conductive and insulating medium, and the power consumption component Nickel-Chromium alloy resistor is packaged therein
19. Over-voltage protection- When input voltage exceeds the safety threshold, it will automatically unload and alarm.
20. Over-current protection - When load main circuit current exceeds the safety threshold, automatically unloaded and protected.
21. Over-temperature protection - When temperature exceeds the safety threshold, it will automatically unload and alarm
22. Fan under-volume protection - When any fan fails to operate normally, it will automatically unload and alarm
23. Operating Atmospheric Pressure - 86 - 106 kPa
24. Operating Temperature -   -10°C to +50°C
25. Humidity -  ≤ 95%
26. Altitude - ≤ 8,200ft
27. Protection Level - IP44 when in storage, IP20 during operation. This is an outdoor type and can be placed outdoors. However, it cannot be tested on rainy days. If a test on rainy days is required, air duct installation is needed.
28. Effectively applied for full load test of generator set, UPS and other AC power systems.
29. Sectionalized control of input power enables any customized setting of load step and time
30. Real-time display of test current, voltage, power, power factor, time and frequency.
31. Alternative control modes by local control of circuit breaker/push button or PC control
32. Emergency stop button for quick termination of AC load test
33. Protection upon over load, over voltage, over temperature, short circuit and so on
34. It adopts latest load element with high density power, safer and more durable
35. Axial flow fans with big blast capacity for quick ventilation with low noise.
