8086 Microprocessor Training Kit with LCD 16*2

1. Microprocessor based Training Kit with Graphical LCD Display and IBM/PC keyboard, On Board Assembler & Dissembler Based on Intel's 8086/8088 CPU @ 20 MHz
2. Compatible with 8088 Microprocessor (8 bit)
3. Provision to add 8087 Co-processor & 8089 I/O Processor 128KB of CMOS RAM using 62256
4. 128 KB of EPROM loaded with monitor expandable further using 27010
5. Battery Backup for RAM
6. Total on Board memory expansion to 384 KB
7. 48 programmable I/O lines through 8255
8. Real time Clock interfaces (Optional)
9. Three 16-bit Timer/Counter through 8253
10. On board USB interface through 8251 for connecting kit to PC
11. 8 different level of interrupt through 8259
12. 1 Maskable interrupt; 8 Non-Maskable interrupts
13. On board Graphical LCD 128*64 with 8 Line
14. On Board USB Interface for PC Interfacing
15. 104 Keys IBM Compatible Key Board (USB)
16. On Board Assembler/Dissembler
17. On Board Traffic Light Controller with 1 intersection having 4 RED LEDs, 4 Yellow LEDs and 8 Green LEDs
18. On Board Stepper Motor Interface to drive 2 Stepper Motors
19. Stepper Motor: No of Steps per Rotation: 48 (7.5 Deg/Step),
20. Drive Method: 2-2 Phase, Drive Circuit: Bipolar Chopper,
21. Magnetic Material: Polar anisotropy ferrite sintered magnet MS500, Enclosed in a metal box with Pointer and 360 Degree Dial
22. On Board Digital Output SMD LED - 8 Nos
23. On Board Digital input – 8 Nos
24. Two modes of Commands: keyboard mode and serial mode
25. All address data and control lines available at 50 PIN FRC connector as per multi Bus
26. Facility for Down/Up loading files from/to PC With Built in Power Supply (5V, +12V, -12V & GND)
27. Enclosed in an ABS Plastic Box with cover for protection against dust
28. All the interfaces stated should be on a single Double sided PTH PCB for reliability
29. Supplied with Detailed User Manual
