8155 Ppi With Timer Card + Frc
Order Code: 43277
Category: Embedded Trainers
Study Cards can be connected to the 50 Pins KXT Bus of any 8/16 bit Series Microprocessor Trainer Kits. In this Study Card LED's are provided for different signals like Read, Write, Address Lines, Data Lines, Chip Select & Port...
SPECIFICATION
8253 (PTC) STUDY CARD
- Three channel Timer/Counter using 8253 Programmable Timer Counter IC.
- All Input/Output ports pins are terminated on terminals & 10 pin FRC Connector.
- Clock for Counter-0 is internally provided.
- Data lines from AD0 to AD7 are indicated by 3mm LEDs.
- Chip Select, A0, A1, Read, Write are indicated by 3mm LEDs.
- Hardware Single Step and Full Clock Execution modes are provided.
- Single stepping can be performed using micro switch provided on board.
- Card are supplied in Australian Pine Wood Enclosure.
- Using this study card all MODE experiment can be performed.
- Interface 8085/8086 Kit using 50 pin FRC Connector.
- User's Manual with Sample Programs..
