SALIENT FEATURES :
High quality xashing xenon lamp which can start to test directly without preheating.
Powerful functions like Photometric measurement, Quantitative measurement, Kinetics, Spectrum Scan, DNA/Protein test, Multi-wavelength test, etc.
In-house massive memory is capable of saving up to 1024M for test data & working curves.
Supports USB storage, The USB port can be used for data transfer, which is easily exported to Excel for further processing, analysis and storage
Large sample chamber can accommadate 5-100mm cuvettes of all kinds. Provide at Extra cost.
Extensive accessories are optional, such as auto 8-cell holder, peltier/sipper system, 21 CRR compliant software Provide at Extra cost. etc.
Auto Wavelength Setting
Tungsten/Deuterium Lamp can be Turned ON/OFF Individually to Extend Lifetime
On-Screen Standard Kinetic Carve Display


TECHNICAL SPECIFICATION
Optical System    :    Double Beam, Grating 1200 lines/mm
Wavelength Range    :    190 nm-1100nm
Spectral Bandwidth    :    1 nm
Wavelength Accuracy    :    ±0.1nm656.1nm, ±0.3nm@all
Wavelength Repeatability    :    £ 0.1 nm
Photometric Accuracy    :    0.2%T(0~100%T),±0.002A(0-0.5A),±0.004A(0.5-1A)
Photometric Repeatability    :    £0.15%T(0-100%T), 0.001A(0-0.5A), 0.002A(0.5-1A)
Photometric Range    :    0-200%T, 0.3-3A, 0-9999C (0-9999F)
Stray Light    :    0.03%T@220nm, 360 nm
Stability    :    ±0.0005A/h@500nm
Baseline Flatness    :    ±0.001A
Noise    :    0.0005A@500nm
Work Mode    :    T%, Abs, Conc, Reflectance, E,
Scanning Speed    :    Hi, Med, Low (Max. 3000nm/min)
Wavelength Setting    :    Auto
Display    :    7" TFT Color Screen
Light Source    :    Imported Xenon Lamp
Detector    :    Imported Silicon Photodiode
Cuvette Holder    :    10mm single hole cell holder
Output    :    USB drive, USB host, Rs232
Power    :    AC 220V/50Hz or AC 110V/60Hz
Shipping Size    :    810x660x390mm
Gross Weight    :    27kg
Standard Accessaries    :    10mm glass cuvette x 4, 10mm quartz cuvette x2, Power cord, User's Manual, PC software
