PNEUMATIC COMPONENTS
Manifold (PM-08)    (Qty:1)
-Operating pressure: 0 - 10bar -Output port x8 with built-in type check valve
-Input connector of 3/2 way hand slide valve -Available for air supply open/close
Start-up valve with filter control valve (P2L-2) (Qty:1)
-Pressure regulation range:0.5 - 8.5bar -Grade of filtration: 40 μm
-Rating flow: 500l/min -Connecting PT1/4, pressure gauge PT1/8 -Differential pressure draining
Pressure regulator valve with gauge (PJY-2) (Qty:1)
-Pressure regulation range:0.5 - 8.5bar -Body material: aluminium alloy -Rating flow: 550l/min
Pressure gauge (PB-B10) (Qty:1)
-Design: Bourdon tube pressure gauge -Display range: 0 - 10 bar -Display glass’s diameter: ø40
One-way flow control valve (PDJL-1) (Qty:4)
-Operating pressure: 0.5 - 9.5bar -Free flow (Out to In) rate : 400l/min
-Controlled flow (In to Out) rate : 200l/min
Single-acting cylinder (PG1-2575) (Qty:1)
-Operating pressure: 1.5 - 10bar -Stroke length: max.75mm -Operating speed: 50 - 800mm/s
-Cylinder’s inner diameter: ø25 -Built-in crash cushion
Double-acting cylinder (PG2-25125) (Qty:2)
-Operating pressure: 1.5 - 10bar
-Stroke length: max.125mm
-Operating speed: 30 - 800mm/s
-Cylinder’s inner diameter: ø25
-Built-in crash cushion
acting cylinder (PG2-25125S) (Qty:2)
-Operating pressure: 1.5 - 10bar -Stroke length: max.125mm
-Operating speed: 30 - 800mm/s -Cylinder’s inner diameter: ø25 -Built-in crash cushion & sensor magnet
9) 3/2-way roller lever valve, normally closed (PJ-2G23NC) (Qty:2)
-Operating pressure: 0 - 8bar -Return type: spring
-Normally closed type -Bi-directional roller lever direct operational valve
3/2-way valve with pushbutton actuator, normally closed (PJ-A23NC) (Qty:1)
-Operating pressure: 0 - 8bar -Direct operational valve
-Normally closed type -Push button operation
3/2-way valve, pneumatically actuated at one end (PQ-231) (Qty:2)
-Operating pressure: 1.5 - 8bar -Normally close type
-Return type: spring and pilot -Spool valve
-Motion frequency: 5 per second
5/2-way valve with selector switch (PJ-X25) (Qty:1)
-Operating pressure: 0 - 8bar
-Direct operational valve
-Return type: spring
-Two-position selector switch
5/2-way valve, pneumatically actuated at one end (PQ-251) (Qty:1)
-Operating pressure: 1.5 - 8bar
-External air control
-Return type: spring and pilot
-Spool valve
-Motion frequency: 5 per second
5/2-way double pilot valve, pneumatically actuated at both ends (PQ-252) (Qty:2)
-Operating pressure: 1.5 - 8bar
-External air control
-Return type: pilot, self-holding
-Spool valve
-Motion frequency: 5 per second
5/2 hand directional valve (PQ-25SD) (Qty:1)
-Operating pressure: 0 - 10bar    -Return type: manual -Spool valve -Swing angle: ±15°
Shuttle valve (OR) (PSF-1) (Qty:2)
-Operating pressure: 0.5 - 9.5bar -Proof pressure: 15bar -Circulation volume: 0.56 -Net sectional area: 10mm2
Dual-pressure valve (AND) (PSYF-1) (Qty:1)
-Operating pressure: 0 - 10bar -Proof pressure: 15bar -Circulation volume: 0.56 -Net sectional area: 10mm2
Non-return valve, delockable (PYD-1) (Qty:2) -Operating pressure: 0.5 - 9.5bar -Operating frequency: 60 pe 24mm2
Quick-exhaust valve (PKP-1) (Qty:1)
-Operating pressure: 0 - 9bar -Circulation volume: 0.56 -Net sectional area: 10mm2
Pneumatic timer, normally closed (PYS-23N) (Qty:1)
-Operating pressure: 2 - 10bar -Time delay: 1 - 30s
-Delay error: 8% -Type: 3/2 way, inner air reset -Transfer time: 30ms
Pressure sequence valve (PSX-L6) (Qty:1)
-Operating pressure: 1 - 8bar -Net sectional area: controlled flow (10mm), free flow (10mm2)
-One way valve opening pressure: 0.3bar -Leakage rate 50l/min, response time: 0.3s -Pressure setting screw (av
