ALL GEARED DRIVE SHAPING MACHINE (Shaper)
Order Code: 26279994.1.24
Category: General Lab Equipment V
ALL GEARED DRIVE SHAPING MACHINE (Shaper)
SPECIFICATION
Type: Horizontal ram-type metal shaper for machining flat surfaces slots, keyways, T-slots, and angular surfaces by means of a single point cutting tool attached to a reciprocating ram.
Max Shaping Length (stroke): Minimum 350 mm
Max Ram to Table Distance: Minimum 330 mm
Max Table Horizontal Travel: Minimum 4000 mm
Max Table Vertical Travel: Minimum 270 mm.
Max Ram Overhang from Column: Minimum 550 mm
Table Rotation (Without Vise): ±90°
Table Rotation (With Vise): ±55°
Turret Vertical Travel: Minimum 110 mm
Ram Strokes per Minute: 4 settings: 32, 50, 80, 125 str/min
Table Feed per Stroke-Horizontal: 0.21 mm (1 tooth), 0.84 mm (4 teeth) per stroke
Table Feed per Stroke-Vertical: 0.18 mm (1 tooth), 0.73 mm (4 teeth) per stroke
Main Motor: Minimum 1.5 kW, 1,400 rpm, 380V, 3-phase, 50Hz
Machine Weight: 1,100-1,250 kg approx
Geometric Accuracy: Ram travel straightness ≤0.05 mm per 300 mm travel (ISO 230-1)
Machine Vise: Swiveling machine vise , minimum 150 mm jaw width
Tool Bits: Set of HSS shaper tool bits (assorted profiles -roughing, finishing, slotting).
Foundation Bolts :Foundation bolts. leveling wedges, and alignment instructions.
Manual: Complete English-language O&M manual (print+ USS). Electrical drawings included.
