Analog Circuits Training Platform
SPECIFICATION
Breadboard for Circuit design
DC power supply: +5V,1A
(Fixed); +12V, 500mA (Fixed);
?12V, 500mA (Variable) AC
power Supply: 9V-0V-9V,
500mA Function Generator:
Sine, Square, Triangle (1Hz to
10 no.
100KHz) Modulating Signal
Generator: Sine, Square,
Triangle (1Hz to 10KHz).
Voltage, current and frequency
on board LCD display. PC
Interface – Acquisition from
two analog input channel
Simulation Software
Modules: Diode
Characteristics (Si, Zener,
LED) Rectifier Circuits Diode
as Clipper Circuit, Diode as
Clamping Circuit, Zener as
voltage regulator.
