SPECIFICATIONS

• Wavelength Range - 190nm to 900nm
• Light Source - 8-Lamp Turret 2 Positions for High-Performance Lamp
• Lamp Current Range - 0 To 15ma
• Optical System Filter - Czemy-Turner Monochromator
• Diffraction Grating - Groove:1800 Lines/Mm Blaze Wavelength: 250nm
• Focal Length - 277mm
• Spectral Bandwidth - 0.1nm, 0.2nm, 0.4nm, 0.8nm, 1.6nm (Automatic Change)
• Optical System Features - Automatic Peak-Picking, Spectral Bandwidth Setting, Energy, And Wavelength Optimization
• Flame System Burner - 10cm Ti Burner Head and Emission Burner
• Spray Chamber - Direct Forming Spray Chamber
• Spray Chamber Material - Corrosion-Resistant PPS Material
• Graphite Furnace System - Heating System Temperatures:3000°C
• Heating Rate: 2500°C/S
• Temperature Control Modes - Optical And Constant Voltage
• Temperature Programming - Slope And Stepped Temperature Programming
• Separate Control System - For Inner Gas, External Gas, And Make-Up Gas
• Safety Protection Function - Hardware And Software Dual Alarm Automatic Flame Shut- Off Gas Supply, Cut-Off Ignition Failure Alarm, Fuel Gas Leakage Alarm, Flow Control
• Errors Alarm, Flame Condition, Air Pressure Monitoring
• Background Correction - D2 Lamp Background Correction S-H Background Correction
• Correction Ability - Over 30 Times
• Operation Software - Compatible With Win XP, Win7, Win8, Win10
• Max Power Consumption - 0.2kva
• Power Supply - Single Phase AC, 110V/220V
• GF Power Consumption - 5.5kva
• GF Power Supply - Single Phase AC, 220V
• Dimensions - (L × W × H) 1020 × 530 × 500mm
• Weight - 85kg
