Module One: Basic Electronic Circuits –

• Diode and Transistor Switches
• Basic applications of Operation Amplifiers (I)
• Inverter OP Amplifier fin 1 kHz and Vin 2 VPP
• Inverter fin 1 kHz and Vin 2 VPP
• Non-Inverter OP Amplifier fin 1 kHz and Vin 2 VPP
• Voltage Follower fin 1 kHz and Vin 2 VPP
• Basic Applications of Operation Amplifiers (II)
• Comparator Vs ±12 V, Vref ±1 V
• Zero Crossing Detector Vs ±12 V, Vref 0 V
• Photoelectric Controller Vs ±12 V, Vref 6 V

Module Two: Waveform Generator Circuits –

• Schmitt Trigger Circuit
• Schmitt Trigger Vs ±12 V, fin 1 kHz, Vin 10 VPP
• 555 Delay Circuit Vs 12 V, Ton 6 secs
• Delay Turn off Circuit VCC 12 V, Ton 4 ~ 9 secs
• Astable Multivibrator
• OPA Astable Multivibrator Vs ±12 V, Vout 22 VPP Square wave
• 555 Astable Multivibrator VCC 12 V, Vout 11 VPP Square wave
• Sparkling Lamp
• Crystal Oscillator
• TTL Crystal Oscillator fo 100 kHz ~ 4 MHz
• OPA Crystal Oscillator fo 1 MHz, Vout 6 VPP

Module Three: Digital Circuits -

• BCD Adder: IC 4560B
• BCD Subtractor: IC 4560B, 4561B
• Applications of Timer
• Monostable Circuit Vcc 12 V, Ton 5 ~ 10 seconds
• Touch Switch Vcc 12 V, Ton 5 secs
• Alarm Circuit Vcc 5 V, IC 555, Speaker
• Digital Display Circuit
• 4518 Counter
• Digit Display Circuit Vcc 5 V, IC CD4518
• Application of LCD
• LCDM Circuit Vcc 5 V, IC: 4511

Module Four: Signal Process Circuits –

• Digital to Analog Converter
• R 2R Ladder Network Vcc 8 V, Vout= 0 ~ 7.5 V
• D/A Converter Vs ±15 V, IC DAC0800
• Analog to Digital Converter
• A/D Converter Vcc 5 V, IC ADC0804
• Filters: Low, High, Bandpass and Bandstop Filter

Module Five: Regulated DC Power Supply -

• Applications of 7800 Series Regulator
• 7805 Regulator Characteristic Vin 8 ~ 15 V, Vout 5 V
• 7805 Expanded Voltage Vin 12 V, Vout 5 ~ 7 V
• 7805 Variable Regulator Vin 12 V, Vout 11 V
• 7805 Current Source RL 0 ~ 330?, Iout 10 mA
• Applications of 7900 Series Regulator
• 7905 Regulator Characteristic Vin 8 ~ 15 V, Vout -5 V
• 7905 Expanded Voltage Vin -12 V, Vout -5 ~ -7 V
• 7905 Variable Regulator Vin -12 V, Vout -11 V
• 7905 Current Source RL 0 ~ 330?, Iout 11 mA

Module Six: LED and Transistor Application Circuits –

• Electronics competition-answer machine
• Remote lamp controller
• Electronic wheel amusement machine
• 02 Sets of 12,000 BTU Cooling facility including accessories
