SPECIFICATION
Cnc milling
WORKING AREA
- Table dimensions: 600 mm x 300 mm
- Table load capacity:150 kg
- Number of T-slots :3 positions
- T-slots, width: 14 mm
- T-slots, spacing: 100 mm
- Spindle nose-to-table surface distance 100 mm - 580 mm
TRAVELS
- Travel X-axis: 400 mm
- Travel Y-axis: 230 mm
- Travel Z-axis: 450 mm
HEAD STOCK
- Spindle speed: 8000 1/min
FEED
- Rapid feed X-axis: 12000 mm/min
- Rapid feed Y-axis: 12000 mm/min
- Rapid feed Z-axis: 10000 mm/min
- Work feed X-axis: 1 mm/min - 10000 mm/min
- Work feed Y-axis: 1 mm/min - 10000 mm/min
- Work feed Z-axis: 1 mm/min - 10000 mm/min
TOOLING
- Number of tool stations:12 positions
- Tool Ø: 100 (130) mm
- Tool length (max.): 300 mm
- Tool weight max.: 8 kg
- Tool-change time tool/tool: 7 sec
DRIVE CAPACITY
- Motor rating main drive: 3,7 kW
- Motor rating X-axis: 0,75 kW
- Motor rating Y-axis: 0,75 kW
- Motor rating Z-axis: 1 kW
MEASURES AND WEIGHTS
- Overall dimensions (length x width x height): 2.1 m x 1.9 m x 2.45 m
- Weight: 2200 kg
