Data Acquisition Unit (DATALOGGER)
SPECIFICATION
Data Acquisition Unit (DATALOGGER)
- General requirements Installation, training and commissioning to be done by the supplier.
- Packing list
Features
- battery operated with rigid carrying case suitable for
- In-built use on field
- 6" touch screen colour graphic display
- Separate display for battery status
- 8 independent input channels
- Display of readings and graphs in real time
- Unlimited storage capacity with USB pen drive
- Contemporaneous data sampling of all channels in accordance to the programmable logging mode
Technical specifications
- Number of channels: 8
- Compatible with load cells, pressure transducers, strain gauges,
- LDT/LVDT/potentiometric displacement transducers
- Communication port: LAN/Ethernet
- Real resolution: 131,000 points
- Data storage on removable USB pen drive
- Sampling rate: up to 10 readings per second per channel via
- USB (up to 500 readings per second per channel via LAN when connected to a PC)
- Excitation (VEXC): from 1 V to 10 V for each couple of channels (up to 4)
- Input signal: 0-10 V; 0-20 mA
- Battery operated: internal rechargeable sealed battery 12V. 7.2 Ah and builtin battery charger 110-230 V, 50-60 Hz, 1 ph.
- Power cable is included
- Battery life: 8 hours in continuous use
- Dimensions approx. [mm]: 265x171x223
