SPECIFICATION
FIRE ALARM TRAINER
Description
The Fire Alarm Trainer is a comprehensive educational system designed to demonstrate the operation, monitoring, and control of conventional fire alarm systems. It enables hands-on training on system indications, fault diagnostics, isolation functions, and emergency operations commonly used in commercial and industrial fire detection installations.
Functional Features
- Mains and DC ON indication
- Mains failure indication
- Battery failure indication
- Charger failure indication
- Bell line failure indication
- Zone fire, fault, and isolate indication
- Evacuate switch with status indication
- Buzzer isolate switch with indication
- Bell isolate switch with indication
- Fire station isolate with indication
- Auxiliary trip isolate switch with indication
- Test zone alarm, fault, and isolate switch
- Master reset push-button switch
Technical Specifications
Electrical
- Power Supply Input : 240 V AC, 50 Hz
- Battery Charger : Automatic / trickle charging
- Charging Current : 300 mA (normal), 2.5 A (boost)
- System Operating Voltage : 24 V DC
Outputs & Interfaces
- End-of-Line Resistance : 8.2 kΩ
- CMS Output : Normally Open (N/O) contact
- Auxiliary Output : 24 V DC, 1 A
Current Consumption
- Standby Mode :
- Master panel : 75 mA
- Per zone with detector : 5 mA
- Alarm Mode :
- Master panel : 140 mA
- Per triggered zone : 70 mA
