FPGA Standard Trainer and Development Board
Order Code: 22235680.3
Category: General Lab Equipment I
FPGA Device Intel (Altera) Cyclone V SX SoC (preferably 5CSXFC6D6F31C6N) - 110K programmable Logic elements, 41509 ALMs- 5,761 Kbits embedded memory- 6 FPGA PLLs and 3 HPS PLLs- 2 Hard Memory ControllersARM- Based Hard Processor System (HPS):- 9...
SPECIFICATION
- FPGA Device Intel (Altera) Cyclone V SX SoC (preferably 5CSXFC6D6F31C6N) - 110K programmable Logic elements, 41509 ALMs- 5,761 Kbits embedded memory- 6 FPGA PLLs and 3 HPS
- PLLs- 2 Hard Memory ControllersARM- Based Hard Processor System (HPS):- 925 MHz, Dual-Core ARM Cortex-A9 MPCore Processor- 512 KB of Shared L2 Cache- 64 KB of Scratch RAM- Multiport SDRAM Controller with Support for DDR2, DDR3, LPDDRl, and LPDDR2- 8-Channel Direct Memory Access (DMA) Controller
- Configuration and Debug:- Serial Configuration Device — EPCS128 on FPGA- On-Board USB Blaster II (Normal Type B USB Connector)Memory Device:- 64MB (32Mx16) SDRAM on FPGA- 1GB (2x256Mx16) DDR3 SDRAM on HPS-
- MicroSD Card Socket on HPSCommunication:- Two USB 2.0 Host Ports (ULPI Interface with USB Type A Connector) on HPS- USB to UART (Micro USB Type B Connector) on HPS - 10/100/1000 Ethernet on HPS- PS/2 Mouse/Keyboard - IR Emitter/Receiver Connectors:- One 40- pin Expansion Header (Voltage Levels: 3.3V)- One HSMC
- Connector(Configurab1e I/O Standards 1.5/1.8/2.5/3.3V)- One 10-Pin ADC
- Input Header- One LTC Connector (One Serial Peripheral Interface (SPI) Master, One I2C and One GPIO Interface ) on HPS Disp1ay:- 24-bit VGA DAC- 128x64 Dots LCD Module with Backlight on HPSAudio:- 24-bit CODEC, Line-in, Line-out, and Microphone-In JacksVideo Input:- TV Decoder (NTSC/PAL/SECAM) and TV- In ConnectorADC:- Sample Rate: 500 KSPS- Channel Number: 8- Resolution: 12 bits- Analog Input Range : 0 4.096 VSwitches, Buttons and Indicators:- 5 User Keys (FPGA x4, HPS x1)- 10 User Switches (FPGA x10)- 11 User LEDs (FPGA x10; HPS x 1)- 2 HPS Reset
- Buttons - 7-Segment Display x 6 Sensors:- G-Sensor on HPSPower:- l2V DC InputSoftware:- Installed with builder softwares - Preferably DEl0-Standard
- Accessories: -GPIO cable- MicroUSB to USB OTG cable- Four port USB hub- HSTC high speed cables (female ends, and male ends)-USB cable 1.8 m- USB WiFi Dongle- 32GB MicroSD card
