Horizontal laminar flow clean bench

1. Brand New Horizontal Laminar Flow Cabinet
2. Application: Laminar Flow Cabinet is used only for sample protection. Laminar Flow Cabinet is a work bench or similar enclosure, which creates a particle-free working environment by taking air through a filtration system and exhausting it across a work surface in a laminar or unidirectional air stream.

Technical Specifications:

1. - Externa Size (W×D×H) mm: 1300 × 820 × 2040 (±50mm)
2. - Internal Size (W×D×H) mm: 1200 × 500 × 570 (±50mm)
3. Display: LCD display
4. Work Surface Height: approx. 750mm
5. Airflow Velocity: Min. 0.3 m/s to Max. 0.5m/s
6. Material:
7. ?  • Main Body: Cold-rolled steel with anti-bacteria powder coating
8.   • Work Table: 304 stainless steels
9.   • Side and Front Window: 5mm toughened glass, anti-UV
10. Pre-filter: Polyester Fiber, washable
11. HEPA Filter: 99.995% efficiency at 0.3 μm
12. Noise: <65dB
13. Front Window: Motorized
14. Max Opening: Approx. 430mm
15. LED Lamp: at least 12W
16. UV Lamp: at least 30W, Emission of 253.7 nanometers
17. Waterproof Socket: at least 2 Socket, total load≤500W
18. Caster: Universal caster with levelling feet
19. Power Supply: AC 220V-240V
20. Included UPS: At least 5KVA

Standard Requirement

1. Standard and Compliance: ISO 9001:2015 certificate or equivalent.
2. Supplier Requirement Experiences: at least 5 years.
3. Language: English language available on machine and manual.
4. Warranty: At least 2 years on Mechanical, Electrical parts and Services.
5. Include Installation and Training:
6.   • On-site installation performed by certified technicians.
7.   • User training covering equipment, full operation,?maintenance, (minimum 1 full training session) at least 2? trainees.
8.   • Provision of training materials, including user manuals
