Technical Specification

Working size

100 x 100 x 100 cm ( H x W x D)

Chamber volume

1000 ltr.

No of trays

03 Numbers

Rating

2.5 KW

Outer Chamber

CRC - powder coated

Inner chamber

Made of Stainless Steel S.S. 304 mirror polished material.

Temperature Range

50 °C to 250 °C

Exterior body

Made of mild steel material, which is powder coated in attractive shades

Insulation

65mm high density Glass wool insulation on all sides to offer minimum chamber heat loss

Heating element

Oven is fitted with heating elements on all three sides, ensuring uniform temperature distribution throughout the working chamber

Heater

Sealed and enclosed heaters to working chamber for minimum heat loss

Temperature Control

Microprocessor based Auto tune PID Digital temperature indicator cum controller

Heating element

80/20 nichrome heating elements, ensuring long lasting and continuous heating within the chamber

Control Accuracy

± 1°C or better

Door lock

Special heavy duty Stainless steel lock and door hinges with spring and roller mechanism

Shelves

S.S. crimped wire mesh Shelves to withstand heavy load and to offer minimum resistance to air circulation for better heat distribution

Other provisions

Provision to add more shelves, as per requirement of test Adjustable Shelves to place test samples or Glass ares of varying dimensions

Air ventilation

Adjustable air ventilation mounted at top

Forced Air circulation

With built in forced air circulation arrangement for uniform heat distribution inside the working chamber

Complete with

Complete with pilot indicating lamps, 2 meter cord wire and power plug.

Operation on

220/230 Volt, 50 Hz, Single phase, AC Supply

Overall Dimensions

1205 X 1335 X 1535 (L X W X D) mm
