IoT-Based Advanced PLC–SCADA Trainer Board

Specifications

Programmable Logic Controller (PLC): Siemens S7-1200 CPU 1214C, integrated digital I/O, expandable with:

• Analog input/output modules
• Temperature measurement module (RTD, Thermocouple)
• PROFINET and Modbus communication capability

Supervisory Control & Data Acquisition (SCADA):

• Siemens TIA Portal V19 software, WinCC Advanced/Professional
• Licensed for educational/industrial training use
• Runtime environment for local and remote monitoring/control

Human–Machine Interface (HMI): Siemens KTP400 Basic, 4 - inch TFT touchscreen, PROFINET interface IoT & Networking:

• Industrial-grade 4G/5G LTE VPN cellular router
• Secure cloud access for remote monitoring/control
• LAN and WAN connectivity options

Motor Control Systems:

• Siemens SINAMICS V20 Variable Frequency Drive (1.5 kW)
• Delta AC Servo Drive and Motor (400 W)
• Induction Motor, 3-phase, 0.75 kW

Sensors:

• Inductive proximity sensors
• Capacitive proximity sensors
• Photoelectric sensors
• Pressure transmitter
• Rotary encoder
• Magnetic contacts
• Limit switches

Actuators:

Double - acting pneumatic cylinders with solenoid valves
Pneumatic actuators and fittings

Pneumatic Supply:

• Portable air compressor, 10 bar working pressure, 20–30 L capacity
• Regulator, lubricator, and associated accessories

Training Modules & Exercises:

• Basic and advanced logic operations
• Motor control via VFD and servo
• Industrial communications (PROFINET, Modbus)
• HMI design and programming
• SCADA project development and deployment
• IoT-enabled monitoring and control
• PID control simulation
• 50+ preconfigured industrial project simulations

PC & Display Unit:

• Intel 12th Gen Core i5 desktop, 16 GB RAM
• Storage: 256 GB SSD + 1 TB HDD
• 19-inch LED monitor
• Pre-installed with required software

Panel & Furniture:

• Custom steel training table with integrated PLC panel
• Mounting space for motors, HMI, drives, and accessories
• Dedicated monitor and CPU stand

Electrical Accessories:

• Control and power cables
• Relays, miniature circuit breakers (MCBs)
• Safety sockets
• Cable lugs and ties
