Losses due to pipe fittings

Order Code: 26279660.10

Category: General Lab Equipment V

Losses due to pipe fittings



SPECIFICATION

Losses due to pipe fittings

  1. The apparatus consists of: Water flow Sensor using discharge of water.
  2. Computer Interface through USB Port with software. (PC & printer is not scope of supply).
  3. A Centrifugal Monoblock Pump 1/2 HP Motor (ISI Kirloskar).
  4. S.S. Sump Tank 55 Ltr. to collect the water.
  5. S.S. Measuring Tank 30 Ltr fitted with piezometer tube to measure the discharge.
  6. Damper is used to collect the water in S.S. MEASURING TANK for certain time.
  7. Pipe & ISI mark Control Valve and regulating valves are used to circulate water.
  8. Bye-pass line is also used to regulate the discharge.
  9. This apparatus consists of: Large bend made up of G.I. Sudden enlargement from 20 mm dia to 25 mm dia.
  10. Sudden contraction from 25 mm dia to 20 mm.
  11. Elbow 20 mm ISI make gate valve of 25 mm dia.
  12. U-tube manometer is connected to pet cock through plastic tubing to measure head difference.
