General Specifications

• Chassis Type: Multi-point electronic injection system for educational purposes

• Engine: 4-stroke petrol engine, 4-cylinders; Displacement 2000 cc

• Gearbox: 5 speeds + reverse

• Differential: Hypoid crown wheel and pinion

• Twin overhead camshaft driven by a toothed belt

• Electronic ignition

• Dual braking circuit

• Rack steering box, rear leaf spring suspension

• Light System: Integrated working front and rear light system controlled by a dashboard for practical demonstrations

• Cutaway Model: Carefully sectioned for training purposes, professionally painted with different colours to better differentiate various parts and cross-sections

• Dimensions: Specific dimensions are not provided but designed for educational settings

Functional Components

• Fuel Injection System: Simulates a multi-point fuel injection system, allowing students to learn about fuel delivery and injection timing

• Sensors Equipped:

  • Throttle Position Sensor (TPS)

  • Acceleration Pedal Position Sensor (APP)

  • Lambda Sensor (O?)

  • Manifold Absolute Pressure (MAP) Sensor

  • Coolant Temperature Sensor

Control and Simulation Features

• ECU: Includes an Engine Control Unit (ECU) that combines ignition and injection control

• Simulation Capabilities:

  • Demonstrates the injection system's behavior under different conditions (cold start, warm start, etc.)

  • Fault simulation capabilities for troubleshooting practice
