Pneumatic Simulator

Simulator Specifications:

1. Should have 60 types of virtual components in the 3D format which makes it identical to the real life components

Pneumatics:

1. Direction control (switch) : 5 types -3/2-Way Push Button Valve (N.C.), 3/2-Way Push Button Valve (N.O.), 5/2-Way Selector Switch Valve, 3/2 Way Selector Switch Valve (N.C.), 3/2-Way Emergency Switch Valve (N.O.)
2. Direction control (roller lever) : 4 types -3/2-Way One-Way Roller Lever Valve (Left) N.C., 3/2-Way One-Way Roller Lever Valve (Right) N.C, 3/2-Way Bidirectional Roller Lever Valve (Left) N.C., 3/2-Way Bidirectional Roller Lever Valve (Right) N.C.
3. Direction control (pneumatic operation): 8 types- 3/2-Way Pneumatic Operated Valve (N.C.), 3/2-Way Pneumatic Operated Valve (N.O.), 5/2-Way Unilateral Pneumatic Operated Valve, 5/2-Way Bilateral Pneumatic Operated Valve, 2/2-Way Unilateral Pneumatic Operated Valve, 5/3-Way Bilateral Pneumatic Operated Valve (PABR Block), 5/3-Way Bilateral Pneumatic Operated Valve (ABR Connection), 5/3-Way Bilateral Pneumatic Operated Valve (PAB Connection)
4. Direction control (solenoid) : 7 types- 3/2-Way Unilateral Solenoid Valve (N.C.), 3/2-Way Unilateral Solenoid Valve (N.O.), 5/2-Way Unilateral Solenoid Valve, 5/2-Way Bilateral Solenoid Valve, 5/3-Way Bilateral Solenoid Valve (PABR Block), 5/3-Way Bilateral Solenoid Valve (ABR Connection), 5/3-Way Bilateral Solenoid Valve (PAB Connection)
5. Pressure/flow control : 4 types- Pressure Control Valve, One-Way Flow Control Valve, Rapid Exhaust Valve, Check Valve
6. Actuator : 9 types- Pneumatic Single-Acting Cylinder, Pneumatic Single-Acting Cylinder (With Flow Control Valve Attachment), Pneumatic Double-Acting Cylinder (With Air Cushion), Pneumatic Double-Acting Cylinder (With Flow Control Valve Attachment), Pneumatic Double-Acting Cylinder (With Proximity Switch Attachment), Rotary Cylinder, Vacuum Generator & Suction Cup, Pressure Gauge, Pressure Switch (Pneumatic to Electric Signal Conversion)
7. Sensor : 11 types - Photo Sensor (Direct Reflection Type, PNP), Photo Sensor (Direct Reflection Type, NPN), Photo Sensor (Direct Reflection Type, NPN), Fiber Optic Sensor (Direct Reflection Type, PNP), Fiber Optic Sensor (Direct Reflection Type, NPN, Capacitive Proximity Sensor (PNP, Capacitive Proximity Sensor (NPN), Inductive Proximity Sensor (PNP), Inductive Proximity Sensor (NPN)
8. Electrical control module: 9 types- Relay Module, Digital Module, Switch Module etc.
9. Auxiliary devices : 6 types

Hydraulics:

1. Pressure control: 7 types- Input Relief Valve (Direct Acting), Input Relief Valve (Indirect Acting), Input Sequence Valve, Pressure Relief Valve (Externally Operated), Pressure Reducing Valve, Counterbalance Valve, Pressure Relief Valve (Cam Operated)
2. Flow rate control: 8 types- One-Way Flow Control Valve, Bidirectional Flow Control Valve, Pressure Compensated Flow Control Valve, Check Valve (1 bar), Check Valve (5 bar), Check Valve (Indirect Acting), Shut-off Valve, T-Connector
3. Direction control (basic type): 13 types- 2/2 Way Hand Lever Valve (N.C), 2/2 Way Hand Lever Valve (N.O), 3/2 Way Hand Lever Valve (N.C), 3/2 Way Hand Lever Valve (N.O), 4/2 Way Hand Lever Valve, 2/2 Way Roller Lever Valve (N.C), 2/2 Way Roller Lever Valve (N.O), 4/3 Way Hand Lever Valve (PT Bypass), 4/3 Way Hand Lever Valve (PT Bypass) A, 4/3 Way Hand Lever Valve (PABT Block), 4/3 Way Hand Lever Valve (ABT Connection), 4/3 Way Hand Lever Valve (ABT Connection), 4/3 Way Hand Lever Valve (PAT Connection)
4. Direction control (solenoid): 12 types- 2/2 Way Left-Sided Solenoid Valve (N.C), 2/2 Way Left-Sided Solenoid Valve (N.O), 3/2 Way Left-Sided Solenoid Valve (N.C), 3/2 Way Left-Sided Solenoid Valve (N.O), 4/2 Way Left-Sided Solenoid Valve, 4/2 Way Both-Sided Solenoid Valve, 4/3 Way Both-Sided Solenoid Valve (PT Bypass), 4/3 Way Both-Sided Solenoid Valve (PT Bypass), 4/3 Way Both-Sided Solenoid Valve (PABT Blocking), 4/3 Way Both-Sided Solenoid Valve (PABT Connection), 4/3 Way Both-Sided Solenoid Valve (ABT Connection), 4/3 Way Both-Sided Solenoid Valve (PAB Connection)
5. Actuator: 5 types- Hydraulic Single-Acting Cylinder, Hydraulic Double-Acting Cylinder, Hydraulic Differential Cylinder, Hydraulic Double-Acting Cylinder (Brake Type), Hydraulic Motor
6. Sensor: 12 types- Pressure Switch (Hydraulic - Electric Signal Conversion), Photo Sensor (Direct Reflection Type, PNP), Photo Sensor (Direct Reflection Type, NPN), Fiber Optic Sensor (Direct Reflection Type, PNP), Fiber Optic Sensor (Direct Reflection Type, NPN), Capacitive Proximity Sensor (PNP), Capacitive Proximity Sensor (NPN), Capacitive Proximity Sensor (NPN), Electric Proximity Switch, Electric Limit Switch (Left), Electric Limit Switch (Right)
7. Auxiliary devices: 4 types- Hydraulic Distributor A (2X Connector 3), Hydraulic Distributor B (1X Connector 6), Pressure Gauge, Hydraulic Distributor (with Pressure Gauge)
8. Electrical control module: 9 types
9. Pneumatic/electro-pneumatic and hydraulic and electro-hydraulic practices should available
10. VR System Should be supplied with Simulation as standard
