SPECIFICATION
Single-channel Potentiostat/Galvanostat/Electrochemical Workstation: 2-, 3-, or 4-electrode system.
Automatic potential/current ranging.
Potential range ±10 V.
Current range ±2 A (2 nA–2 A, 10 ranges).
Potential accuracy 0.1% FS ±1 mV.
Current accuracy 0.1% FS.
Potential resolution 10 μV (>100 Hz).
3 μV (<10 Hz).
Current sensitivity 1 pA.
Rise time <1 μs (<10 mA).
<10 μs (<2 A).
Compliance voltage ±30 V.
Reference electrode input impedance 10¹² Ω||20 pF.
Max current output 2 A.
CV/LSV scan rate 0.001 mV s?¹–10,000 V s?¹.
CA/CC pulse width 0.0001–65,000 s.
DPV/NPV pulse width 0.0001–1000 s.
SWV frequency 0.001–100 kHz.
Min potential increment 0.075 mV.
Data acquisition 16-bit@1 MHz.
20-bit@1 kHz.
DA resolution 16-bit (setup 1 μs).
Low-pass filters (8 decades).
EIS: 10 μHz–1 MHz.
AC amplitude 1–2500 mV.
DC bias −10 to +10 V.
50 Ω output.
Waveforms (sine, triangular, square).
Distortion <1%.
Log/linear scan.
Interface USB/Ethernet.
OS Windows 10/11.
