Riffle Sample Divider-G.I
Order Code: 21225380.4
Category: General Lab Equipment I
Specifications:- Used for sampling aggregates, ores, refractory materials, pigments, powdered coal etc. It consists of pcrc sheet box mounted on legs, fitted with a series of chutes of euqalwidth. The chutes of the riffle a...
SPECIFICATION
Specifications:-
Used for sampling aggregates, ores, refractory materials, pigments, powdered coal etc.
It consists of pcrc sheet box mounted on legs, fitted with a series of chutes of euqalwidth.
The chutes of the riffle are sleep enough to allow rapid flowing of the material.
Each riffle sample divider supplied with two pans and one scoop.
Moc : g.i.
Paint : powder coated
- Made from sheet steel and supplied complete with3 metal pans. EN riffle box:
- 5mm Maximum particle size, 7mm slot width, 12 Number of slots, 0.24dm3 Capacity, 15kg Weight.
- 10mm Maximum particle size, 15mm slot width, 12 Number of slots, 2dm3 Capacity, 5kg Weight.
- 20mm Maximum particle size, 30mm slot width, 10 Number of slots, 4.6dm3 Capacity, 19kg Weight.
- 40mm Maximum particle size, 50mm slot width, 8 Number of slots, 14dm3 Capacity, 23.5kg Weight.
- 13mm Maximum particle size, 19mm slot width, 10 Number of slots, 3dm3 Capacity, 5.5kg Weight.
- 25mm Maximum particle size, 38mm slot width, 8 Number of slots, 9.6dm3 Capacity, 19kg Weight.
- 50mm Maximum particle size, 64mm slot width, 8 Number of slots, 21dm3 Capacity, 27kg Weight.
- 35mm Maximum particle size, 45mm slot width, 8 Number of slots, 28dm3 Capacity, 23kg Weight. With Stainless steel sample splitter, sixteen 5 mm slots."
