Sand Bath - Energy Regulator Size 30 x 20 x 10 cm

Order Code: MT686

Applications : A sand bath is a common piece of laboratory equipment made from a container filled with heated sand. It is used to provide even heating for another container, most often during a chemical reaction. Salient Features : Aestheti...

SPECIFICATION

Applications :
A sand bath is a common piece of laboratory equipment made from a container filled with heated sand. It is used to provide even heating for another container, most often during a chemical reaction.

Salient Features :

Aesthetic outer appearance
Unique design of Hot plate with Grooves ? concealed heaters
3 stage heat control switch for selection of LOW, MEDIUM or HIGH heat
Fully air ventilated lower body for minimum heat, even when the top plate is fully heated
Unique design of Hot plate with Grooves ? concealed heaters
Sealed heaters in Grooves ? ensuring long life.

Optional Accessories At extra cost :

Forced air exhaust for continuous duty
Leather gloves for thermal protection

Technical Specification
Construction	Double walled
Inner chamber	of container : Fabricated from stainless steel S.S. 304 material
Outer Chamber	Fabricated from mild steel which is powder coated in attractive shades
Top heating plate	Made up of Cast Iron Material
Temperature Range	50 °C to 300 °C
Temperature Control	Through Energy Regulator
Temperature sensor	RTD (Pt 100) sensor
Control panel	Equipped with mains switch, control switch, pilot lamp and Energy regulator
Heating	Heated by open type heaters placed at the bottom of the inner chamber
Operation on	230 Volts, 50 Hz, Single Phase, AC Supply
Overall Dimensions	330 X 320 X 365(L X W X D) mm
