Shoe lace abrasion machine (Lace to eyelet and lace to lace method)
Order Code: 25268451.2.3
Category: General Lab Equipment V
Shoelace Abrasion Tester Application: The Shoelace Abrasion Tester is designed to test the abrasion resistance of shoelaces against standard eyelets or eyelets against standard shoelaces. It is suitable for testing a wide range of shoelaces and e...
SPECIFICATION
Shoelace Abrasion Tester
Application:
The Shoelace Abrasion Tester is designed to test the abrasion resistance of shoelaces against standard eyelets or eyelets against standard shoelaces. It is suitable for testing a wide range of shoelaces and eyelets to assess their durability under repeated friction.
Features:
-
The shoelace is passed through the eyelet, which is clamped onto a fiber board.
-
The shoelace and eyelet are positioned at a 90-degree angle, while the fiber board and shoelace form a 45-degree angle.
-
The tester applies reciprocating tension on the shoelace under standard conditions provided by the eyelet.
-
Testing automatically stops when the shoelace shows visible damage.
Key Specifications:
| Parameter | Specification |
|---|---|
| Test Positions | 6 positions |
| Weights | 455g ± 5g (6 pieces) |
| Control Method | Touch-screen control, 0–999,999 cycles |
| Standard Eyelet | Brass, inner diameter: 4.5 mm |
| Fiberboard Dimensions | 25 × 25 mm with an inner diameter of 5.0 ± 0.2 mm |
| Movable Stroke | 76 ± 2 mm |
| Test Speed | 100 ± 5 cycles per minute (cpm) |
| Power Supply | 1 AC 220V 50/60 Hz ? |
| Dimensions (W × D × H) | 57 × 58 × 41 cm |
| Weight (Approx.) | 60 kg (excluding weights) |
| Standards | SATRA TM93 |
