Solar Thermal Energy Trainer
Order Code: 25268595.86
Category: General Lab Equipment V
1. Collector Specifications Tube Diameter: 5.5 cm Tube Length: 1.80 m Number of Tubes: 10 Dimensions: Height 2 m × Length 1.30 m × Width 0.16 m Weight: 60 kg Working Pressure: 6 Bar ...
SPECIFICATION
1. Collector Specifications
-
Tube Diameter: 5.5 cm
-
Tube Length: 1.80 m
-
Number of Tubes: 10
-
Dimensions: Height 2 m × Length 1.30 m × Width 0.16 m
-
Weight: 60 kg
-
Working Pressure: 6 Bar
-
Tilt Range: 15° – 75°
2. Tank Specifications
-
Capacity: 120 liters
-
Type: Non-pressurized
3. Electrical Specifications
-
Power Supply: Single-phase 220 VAC, 50 Hz
-
Safety Features:
-
Grounding
-
Coded lock for teacher access
-
Emergency switch
-
Protective earth leakage switch
-
4. Trainer Components
-
Solar collector with adjustable inclination
-
Accumulator tank with internal coil
-
2 recirculating pumps
-
Expansion tank
-
Power supply and electrical safety module
-
Programmable electronic control unit with monitoring probes
-
Regulation, safety, and control valves
-
4 thermo-manometers for pressure and temperature measurement
-
Hoses for fluid circulation
5. Front Control Panel
-
Located at the top of the main module
-
Includes:
-
Block diagram of the system
-
Electronic control center with LCD screen for data visualization
-
Situation lights
-
