Fluids Specific Gravity & Density Apparatus

Order Code: 32100

Category: Fluid Mechanics Lab

Tesca Specific Test Apparatus consists of: Pycnometer bottle Volume : 10ml Material : Glass Precision Electronic Scales Capacity : 500 g Resolution ; 0.1 g Ÿ Accuracy : 0.01 g Ÿ Display : LCD Power : 2 x AAA battery Medium: Water, O...



SPECIFICATION

Tesca Specific Test Apparatus consists of:
Pycnometer bottle
Volume : 10ml
Material : Glass
Precision Electronic Scales
Capacity : 500 g
Resolution ; 0.1 g Ÿ Accuracy : 0.01 g Ÿ Display : LCD
Power : 2 x AAA battery
Medium: Water, Oil with different Specific Gravity

Tesca Liquid Density Apparatus comes with the following features :
Hydrometer:
Triple Scale: Specific Gravity (0.99 – 1.17), Brix/Balling (0-35), Potential Alcohol (0% - 20%)
Color-coded scale: indicates the starting and finishing point
Save time. A convenient 3 in one tool allows the user to quickly and accurately measure vital information on the liquid
Secure & Safe Packaging: Plastic tube cylinder holds hydrometer
Triple scale reading – use all three reading scales for the measurement for experiment exercise
Accurate measurements and the proposed hydrometer is colored in 3 different colors for easier measurement
Hydrometer  Jar  shall  be  made  of  glass material with a minimum volume of 2,000 ml.

Tesca Viscosity Apparatus consists of a capillary tube of fine bore fitted on a wooden board.
Then two ends are joined by a rubber tubing which is joined to two upright L-shaped glass tubes forming the manometer with scale. With the help of a pinch cork, a steady flow of water is maintained. Complete with a three-limbed constant level tank of brass, one stand with a rubber tube, and glass parts of corning glass.
Measures up to tens cm (mm2/s)
Comply with standard ISO/DIS 3105, ASTM D 2515, BS 188 wrt technical measuring specification.
Measures liquid viscometer up to 800 mm2/s or higher.
Filling quantity: @ 2… 10ml
Overall length : @ 200mm
