Bandpass Filter TFB3357-1567SMC
Order Code: TFB3357-1567SMC
Category: Band Pass Filter
Features: Rugged Shielded case Other standard and custom BPF models Small & Rigid design Economical Wide Passband Description: The TFB3357-1567SMC is a band pass filter operates from 2570MHz to 4130MHz frequency rang...
SPECIFICATION
Features:
- Rugged Shielded case
- Other standard and custom BPF models
- Small & Rigid design
- Economical
- Wide Passband
Description:
The TFB3357-1567SMC is a band pass filter operates from 2570MHz to 4130MHz frequency range. The signal output uses a SMA male connector at Input side and SMA Female connector at output side to RF test equipment. Its laboratory quality specifications will meet most engineering laboratory requirements. The same features that make the model RFB3357- 1567SMC a good choice for a lab.
Applications:
- Amateur Radio Equipment’s
- Test and measurement equipment
- Wireless Communication Equipment’s Wearables
- Security systems
- Harmonic Rejection
- Transceivers Communications
- Navigations
|
Electrical Speci?cations: |
|
|
Frequency Range: |
2570MHzto 4130MHz |
|
Center Frequency : |
3350 MHz |
|
Input Power: |
+27dBm (Max.) |
|
Insertion Loss : |
-3.3dB (Max) |
|
Return Loss : |
-10 dB (Min) |
|
VSWR: |
2.3:1 Max |
|
In / Out Impedance: |
50 Ohm |
|
Operating temperature: |
0 ?C to 50 ?C |
|
In / Out Connector: |
SMA (F) |
|
Mechanical Speci?cations: |
|
|
Shape: |
Cylindrical shape |
|
Weight : |
25 gm |
