Conventional internal broaching machine
Order Code: 25268467.10
Category: General Lab Equipment V
TECHNICAL SPECIFICATIONS: Max. Blade Size: 315mm Two different blade speed Saw frame swivels ± 45° Double vise design Equipped with coolant system Auto cutting, hydraulic clampi...
SPECIFICATION
TECHNICAL SPECIFICATIONS:
- Max. Blade Size: 315mm
- Two different blade speed
- Saw frame swivels ± 45°
- Double vise design
- Equipped with coolant system
- Auto cutting, hydraulic clamping
Features:
- Max. Blade Size: 315mm
- Two different blade speed
- Saw frame swivels ± 45°
- Double vise design
- Equipped with coolant system
- Auto cutting, hydraulic clamping
| Max. blade size | 315 mm | ||
| Capacity | @45° (mm) | @90°(mm) | |
| Round Pipe | φ80 | φ90 | |
| ectangular pipe | 60×60 | 80×80 | |
| Motor power | 2.2/3.0 kW (2P/4P double speed) | ||
| Blade Speed | 60/120 rpm | ||
| Travel of main hydraulic cylinder | 130mm, max.10MPa | ||
| Travel of Hydraulic clamping cylinder | 10 mm | ||
| Hydraulic station | 4P, 750W, DC24V, 3MPa | ||
| Drive | Gear | ||
| Packing size | 146x75x166 cm | ||
| N.W/G.W | 460/520 kg | ||
