Module Six: Memory Circuits
Experiment 1: Constructing ROM Circuit with Diodes
Store Data Length: 2 bits; Data Display Mode: LED Display
Experiment 2: Constructing RAM Circuit with D Flip-flop
Input Data Length: 4 bits; Input Data Mode: Dip Switch; Output Data Length: 4 bits; Data Display Mode: LED Display
Experiment 3: Programable ROM Circuit
Experiment 4: 64 Bits RAM Circuit
Input Data Length: 4 bits; Input Data Mode: Dip Switch; Output Data Length: 4 bits; Data Display Mode: LED Display
Module Seven :  Converter Circuits
Experiment 1: OPA ADC Circuit
Analog Input: 0 V-5 V; Data Display Mode: LED Display; Resolution: 4 bits
Experiment 2: ADC0804 ADC Circuit
Analog Input: 0 V-5 V; Data Display Mode: LED Display; Resolution: 8 bits
Experiment 3: 4 Bits R-2R DAC Circuit (Digital Input: 4 bits; Analog Output: 0 V-5 V)
Experiment 4: Unipolar DAC0800 DAC Circuit
Digital Input: 8 bits; Input Data Mode: Dip Switch; Analog Output: 0 V - 5 V; Step Value: 0.019 V
Experiment 5: Bipolar DAC0800 DAC Circuit
Digital Input: 8 bits; Input Data Mode: Dip Switch; Analog Output: -5 V - 5 V; Step Value: 0.038 V
Module Eight: Logic Application Circuits
Experiment 1: Electronic Voting Circuit (7408, 7404, 7432, 7486)
Experiment 2: Electronic Wheel-amusement Circuit (Vcc= 12 V; IC: 555, CD4017B)
Experiment 3: Electronic Competition-answer Circuit (Vcc= 12 V; IC: CD4011 B)
Experiment 4: Traffic Light Circuit (Vcc= 12V; IC:555,CD4017B)
Function Generator & DC Power Supply Module:
Waveforms: Sine, Triangle, Square, TTL Pulse
Amplitude: >10 Vpp
Impedance: 50Ω ±10%
Duty Control: 30% ~ 60%
Display: 6-Digit LED Display
Frequency Range: 10Hz to 100 kHz (4 Ranges), 100Hz to 1 MHz (4 Ranges)
Frequency Control: Separative Coarse and Fine Tuning
Constant Voltage Output: ±5V, ±12V
Variable Voltage Output: 0V ~ ±15V
Power source: 220V AC ±10%, 50Hz
