DIGITAL MODULATION COMMUNICATION TRAINER PCM-TDM
Order Code: 25269219.13
Category: General Lab Equipment V
DIGITAL MODULATION COMMUNICATION TRAINER PCM/TDM
SPECIFICATION
DIGITAL MODULATION COMMUNICATION TRAINER PCM/TDM
Description
The Digital Modulation Communication Trainer (PCM/TDM) is a compact, laboratory-grade training system designed for hands-on study of digital communication techniques. The trainer enables practical understanding of pulse-based modulation methods and multiplexing concepts through integrated signal generation, filtering, and measurement facilities.
Functional Capabilities
- Modulation & Demodulation :
- Pulse Code Modulation (PCM) techniques
- Time Division Multiplexing (TDM)
- Internal Signal Generator :
- XR2206 / 8038 IC–based signal generators
- Signal Types :
- Sine wave
- Square wave
- Signal Frequency Range :
- 200 Hz to 2 kHz
- Sampling / Clock / Line Frequency :
- Up to 200 kHz (maximum)
- Low-Pass Filter :
- Cut-off frequency : 5 kHz
Mechanical Specifications
- Dimensions (W × D × H) : 265 × 185 × 95 mm Approx
- Weight : Approximately 1.5 kg Approx
Electrical Specifications
- Power Supply : 110 V – 260 V AC, 50/60 Hz
Environmental Conditions
- Operating Temperature : 0 °C to 40 °C
- Relative Humidity : Up to 85% RH
