HYBRID AND ELECTRIC SYSTEM SIMULATOR – electrical

1. This simulator allows the study of all the operating features of an automobile with a hybrid system (internal combustion engine and electric motor) or completely electric.
2. It is composed of a panel operated by computer with a silk-screened diagram which explains the positioning of the car components and indicates the features of the system by showing different colours on the panel. Moreover light indicators are on the panel to show for the operation of the system.
3. Through the computer, the teacher can monitor the entire system and the operational states entered by the students. Moreover, the faults can be inserted and checked by the teacher and with the use of the software practical and theoretical topics can be constantly followed.
4. An english manual is supplied together with thw unit.
5. Hybrid system:
6. Intelligent Power Unit
7. Battery unit (Ni-MH cells)
8. ECU battery
9. Electric Unit:
10. Synchronous 3-phase Electric Motor/Generator with
11. Permanent magnets
12. Eco Assist System
13. Gasoline Unit :
14. Gasoline Engine
15. i-DSI
16. i-VTEC
17. ECU
18. CVT
19. A/C Compressor- dual-scroll hybrid mode
20. Cooling Fan
21. Motor Control Module
22. Electric Power Unit
23. DC Unit
24. A/C Driver
25. Electric System
26. High-voltage battery module, (Li-ion cells)
27. Recharging system by external AV
28. 12 V battery and recharging
29. Electric motor control system
30. 3-phase inverter for managing the electric motor
31. Inverter control signals and sensors for the voltage and current measurement
32. 3-phase AC motor with integrated transmission system
33. Integrated sensors in the AC three-phase motor
34. The simulator is complete with Training Software and with Control Software.
35. The software guides the student through the learning,
36. Simulation and experiments performance, tests and troubleshooting.
37. Approx. weight and dim.: Cm: 104x35x66
38. Net Weight: kg 16
