Splitting Tensile Attachment for Concrete Mould And Paver Block Accessories for Compression Testing Machine

Order Code: MT030

Category: Concrete Testing

Compliance with following International Standards: As per IS: 516, IS: 9399, BS: 1881, ASTM C78 Construction Details: 100 kN Capacity flexural machine with Digital Load Indicator cum controller The lower platen has two rollers, the distanc...



SPECIFICATION

Compliance with following International Standards: As per IS: 516, IS: 9399, BS: 1881, ASTM C78

Construction Details:

  • 100 kN Capacity flexural machine with Digital Load Indicator cum controller
  • The lower platen has two rollers, the distance between which is adjustable.
  • For 150 mm x 150 mm x 700 mm beam, the center distance between the rollers is 600 mm, while it is 400 mm for beams  of size 100 mm x 100 mm x 500 mm.
  • The upper platen has also a pair of rollers whose distance is adjustable.
  • The distance between upper roller is 200 mm center to center,  for 150 mm x 150 mm x 700 mm size beam and 133 mm for 100 mm x 100 mm x 500 mm size beam.
  • Overall Dimensions : 740 X 420 X 1120 (L X W X D) mm
