Thermal expansion apparatus

Order Code: 25268481.5

Category: General Lab Equipment V

Objective: To determine the coefficient of linear expansion of a given metallic sample (Copper, Brass, or Aluminum). Features: Accurate measurement using a precision spherometer Electric oven provided for uniform heating of sam...



SPECIFICATION

Objective:

To determine the coefficient of linear expansion of a given metallic sample (Copper, Brass, or Aluminum).

Features:

  • Accurate measurement using a precision spherometer

  • Electric oven provided for uniform heating of samples

  • Buzzer indicator for notifications

  • Supplied with sample materials: Copper, Brass, and Aluminum

Technical Specifications:

Steam Jacket:

  • Material: Brass

  • Length: 50 cm

  • Diameter:

    • Inner: 2.5 cm

    • Outer: 3.0 cm

Test Samples:

  • Materials: Copper, Steel, Aluminium

  • Length: 52 cm

  • Diameter: 10 mm

Spherometer:

  • Main Scale Range: 10–0–10 mm

  • Circular Scale Divisions: 100

  • Least Count: 0.01 mm

Electrical Specifications:

  • Buzzer Indicator Voltage Range: 1.5–15 V DC

  • Power Supply: 230 V AC, 50 Hz

  • Adaptor Output: 5 V DC, 500 mA
