PERFORMANCE : SI

1. Sensitivity(± 5 %) : 10.2 mV/(m/s²)
2. Measurement Range : ± 490 m/s²
3. Frequency Range(± 5 %) : 2.4 to 2000 Hz
4. Frequency Range(± 10 %) : 1.7 to 5000 Hz
5. Frequency Range(± 3 dB) : 0.8 to 8000 Hz
6. Resonant Frequency : 20 kHz
7. Broadband Resolution(1 to 10,000 Hz) : 981 µm/sec2
8. Non-Linearity : ± 1 %
9. Transverse Sensitivity : ≤ 5 %

ENVIRONMENTAL

1. Overload Limit(Shock) : 49,050 m/s² pk
2. Temperature Range : -54 to +121 °C
3. Temperature Response : See Graph

ELECTRICAL

1. Settling Time(within 1% of bias) : ≤ 3.0 sec
2. Discharge Time Constant : ≥ 0.2 sec
3. Excitation Voltage : 18 to 28 VDC
4. Constant Current Excitation : 2 to 20 mA
5. Output Impedance : <100 ohm
6. Output Bias Voltage : 8 to 12 VDC
7. Spectral Noise(10 Hz) : 68.7 (µm/sec2)/√Hz
8. Spectral Noise(100 Hz) : 27.5 (µm/sec2)/√Hz
9. Spectral Noise(1 kHz) : 9.8 (µm/sec2)/√Hz
10. Electrical Protection : RFI/ESD
11. Electrical Isolation(Case) : >108 ohm

PHYSICAL

1. Size (Length x Width x Height) : 38.1 mm x 38.1 mm x 20.8 mm
2. Weight : 139 gm
3. Mounting Thread : 1/4-28 Male
4. Mounting Torque : 2.7 to 6.8 N-m
5. Sensing Element : Ceramic
6. Sensing Geometry : Shear
7. Housing Material : Stainless Steel
8. Sealing : Welded Hermetic
9. Electrical Connector : 4-Pin MIL-C-26482
10. Electrical Connection Position : Side
11. Electrical Connections(Pin A) : X axis
12. Electrical Connections(Pin B) : Y axis
13. Electrical Connections(Pin C) : Z axis
14. Electrical Connections(Pin D) : Ground

SUPPLIED ACCESSORIES:

1. Captive mounting bolt 1/4-28 x .75"
2. traceable single-axis amplitude response calibration from 600 cpm (10 Hz) to upper 5% frequency

OPTIONAL VERSIONS

1. LB- Low Bias Voltage
2. Output Bias Voltage
3. Excitation Voltage
4. Measurement Range : ± 343 m/s²
