• Table Size - 1650x360 mm
•  T Slot - 3 no
•  Size ( Width ) - 14 mm
•  Centre Distance - 95 mm
•  Max. Load Of Table - 300 kg

 MACHINING RANGE

•  Table Longitudinal Travel - 1300 mm
•  Table Cross Travel - 300 mm
•  Table Vertical Travel - 400 mm

 MAIN SPINDLE

 Spindle Taper - ISO50
 Number of Spindle Speed - 12
 Spindle Speed /Step -Horizontal - 58-1800/12steps rpm
 Spindle Speed /Step - Vertical - 60-1750/12steps rpm
 Max. Swivel Angle of Work Table - ±35
 Dist. From Spindle Axis to Table Surface - 0-400 mm
 Dist. From Spindle Axis to Ram Surface - 175-560 mm

FEEDS

•  Feed Range -Longitudinal - 22-420 mm/min.
•  Feed Range -Cross Feed – 22-393mm/min
•  Feed Range Vertical - 6-112 mm/min.
•  Rapid Speed -Longitudinal - 1290mm/min.
•  Rapid Speed -Cross Feed - 1205mm/min.
•  Rapid Speed -Vertical - 400mm/min.

 POWER

•   Motor Power - 4 kw
•  Feed Motor Power - 1.1 kw

 STANDARD ACCESSORIES

•  Stub arbor
•  3 Axis DRO (DIGITAL READ OUT) unit with High Precision Scales & fittings
•  Coolant system
•  Electricals
•  Tool box
•  Instruction manual
•  Safety Guard
•  Spare Arbour with Spacer 25mm

 EXTRA ACCESSORIES (DOESN'T COME WITH THE MACHINE)

•  Universal Dividing Head with 6” Chuck & Spindle Tailstock
•   Universal Dividing Head with 8” Chuck & Spindle Tailstock
•  12” Rotary Table Horizontal with Indexing Device
•  12” Rotary Table Horizontal & Vertical (With Indexing Device)
•   Milling Machine Vice 8” (Swivel base)
•   6” Hydraulic Pressure Vice (150mm with 300mm Opening)
•  Spare Arbour with Spacer 27mm
•  Spare Arbour with Spacer 32mm
•  I.S.O 50 Collect Adopter with Key
•  Collects 8 Pieces Set 4mm. to 25mm.
•  Clamping kit - M12 (58 Pcs.)
•  Micro Boring Head ISO-50
•  Size 9” x 7” x 6” Cast Iron Slotted Angle Plates Plain
•  Size 10” x 8” x 6” Cast Iron Slotted Angle Plates Plain
•  Size 12” x 9” x 8” Cast Iron Slotted Angle Plates Plain
•  Dial comparator stand (Square Serrated)
•  Cast Iron Vee Blocks 125x88x44mm (supplied in match pair with one clamp)
•  Cast Iron Vee Blocks 150x100x50mm (supplied in match pair with one clamp)
•  Cast Iron Vee Blocks 150x100x100mm (supplied in match pair with one clamp)
