Key Features: Gears in headstock and spindle are hardened and precision ground Safety foot brake
Crossway feeding guide screw: 2-point support for heavy cutting.
Bed ways and surface of compound rest are ultra-frequency heat-treated and ground for longer life One-piece Meehanite casting machine base.
Apron-enforced oil supply with safety device to avoid collision Metric & inch gearbox with full range of inch, DP, MP threading and multiple threads — all functions reached without change gear.
Dynamically balanced alloy spindle with 3-point bearing support

Technical Specifications:

Swing over bed: 458 mm
Distance between centers: 1000 mm
Swing over cross slide: 678 mm
Width of bed: 317 mm
Width of gap: 210 mm
Bed length: 1990 mm
Spindle bore: 70 mm
Spindle speed: 80–1800 variable speed
Number of spindle speeds: 12 steps
Spindle nose: A2-6
Width of carriage: 485 mm
Cross slide travel: 250 mm
Top slide travel: 125 mm
Tool shank: 20 × 20 mm
Tailstock: 52 mm
Taper: MT4
Barrel travel: 140 mm
Lead screw diameter & pitch: Ø35 mm, pitch 6 mm
Range of metric pitches: 0.2–14 mm
Range of inch pitches: 2–56 TPI
Range of module pitches: 0.3–3.5 MP (18 Nos)
Range of cross feeds: 0.05–1.25 mm/rev
Feed rod diameter: 22 mm
Range of longitudinal feeds: 0.04–1.0 mm/rev
Coolant pump motor: 1/8 HP
Motor: 5.625 kW
Power supply: 220V / 3P / 60 Hz
Supplied With: Main drive motor X/Z-axes automatic lubrication system Metric/Inch gearbox Coolant system Longitudinal apron motion feed Tailstock two-step device 3-Jaw scroll chuck with backplate Backplate of chuck Steady rest Follow rest Halogen lamp Center sleeve Dead center Live center Tools in toolbox Level pads Operational manual
Digital Readout (DRO) System
Resolution: 0.5 / 1 / 5 Absolute / Incremental (DRO) Save 200 workpiece zero points Zero location auto-reset Cone measurement 200 memory slots Error linear compensation Non-volatile memory Max measuring speed: 60 m/min
Protection class: IP53
Additional Requirements:
Supply, delivery, and installation of lathe machine With manufacturer’s authorization to bid Product brochure 20 hours on-site training 90 calendar days delivery period Two-year warranty for parts Three-year warranty for services User’s manual
Free installation
Preferably not made in China
